The WS-X1181 features a 10th Gen Intel Core X-Series CPU with up to 18 cores and 36 threads professionally overclocked across all cores. This range of Workstations has the perfect blend of high-frequency clock speeds and many cores, making it an exceptionally well-rounded platform. Pairing these powerful processors with a professional NVIDIA Quadro or AMD Radeon Pro graphics makes the WS-X1181 an ideal choice for professionals planning to design as well as Render on the same system.
End of Life
End of Life
| Item Depth (CM) |
39.9 |
|---|---|
| Item Height (CM) |
44 |
| Item Weight (Kg) |
18-22 |
| Item Width (CM) |
21 |
| # Front USB 3.2 Gen 1 Type-A |
2 |
|---|
| # Int USB 2.0 Header |
1 |
|---|---|
| # Int USB 3.2 Gen 2 Header |
1 |
| # Int USB 3.2 Gen1 Header |
1 |
| # M.2 NVMe PCIe 3.0 x4 |
1 |
| # M.2 NVMe PCie 3.0 x4 / SATA |
1 |
| # SATA3 (6Gbps) Ports |
6 |
| # U.2 Ports |
1 |
| DDR Rev. |
DDR4 |
|---|---|
| Max. Memory Capacity (GB) |
256 |
| Max. Memory Channels |
4 |
| Memory Type |
Non-ECC UDIMM |
| PCIe Configuration |
2 x PCIe 3.0 x16 (x16 mode) |
|---|
| Processor Chipset |
Intel X299 |
|---|---|
| Processor Generation |
Intel Core-X 10th Gen. |
| Socket |
2066 |
| # Rear 1Gbps RJ45 Ports |
2 |
|---|---|
| # Rear USB 2.0 Type-A |
4 |
| # Rear USB 3.2 Gen 1 Type-A |
1 |
| # Rear USB 3.2 Gen 2 Type-A |
1 |
| # Rear USB 3.2 Gen 2 Type-C |
1 |
| Supported OS |
Linux, Windows 10, Windows 7, Windows Server 2012 R2, Windows Server 2016 |
|---|
| # Dedicated 2.5Inch Bays |
3 |
|---|---|
| # Universal 3.5/2.5Inch Bays |
2 |
| Warranty Duration |
36 Months |
|---|---|
| Warranty Type |
Return To Base |
The WS-X1181 features a 10th Gen Intel Core X-Series CPU with up to 18 cores and 36 threads professionally overclocked across all cores. This range of Workstations has the perfect blend of high-frequency clock speeds and many cores, making it an exceptionally well-rounded platform. Pairing these powerful processors with a professional NVIDIA Quadro or AMD Radeon Pro graphics makes the WS-X1181 an ideal choice for professionals planning to design as well as Render on the same system.
