WS IXW-C6210 Workstation (Intel® Xeon® W, Up To 3x GPU)

Details & Specifications

Dimensions:

Item Height (CM)	54.8
Item Width (CM)	24
Item Depth (CM)	59
Item Weight (Kg)	16.53

Front IO:

# Front 10Gbps RJ45 Ports	2
# Front USB 2.0 Type-A	2
# Front USB 3.2 Gen 1 Type-A	2
# Front USB 3.2 Gen 2 Type-C	1

Internal IO:

# Int USB 2.0 Header	1
# Int USB 3.2 Gen 2 Type-A	1
# Int USB 3.2 Gen1 Header	1
# M.2 NVMe PCIe 3.0 x4	4
# SATA3 (6Gbps) Ports	8

Memory:

# Memory Slots	12
DDR Rev.	DDR4
Max. Memory Capacity (GB)	3072
Max. Memory Channels	6
Memory Type	ECC LRDIMM, ECC RDIMM

Network:

Network Controllers	1x Intel® Ethernet Controller I210-AT 1x Realtek RTL8211E PHY (dedicated IPMI) 1x Aquantia® AQC107 10G Ethernet Controller

PCIe:

PCIe Configuration	4x PCI-E 3.0 x16 3 PCI-E 3.0 x8 (in x16 slot) PCIe Slot 1 Shares with M.2 Slots (16/NA/16/NA/16/NA/16 or 16/8/8/8/8/8/8)

Processor:

Processor Generation	20496E74656CC2AE2058656F6EC2AE20572D333278782050726F636573736F72
Socket	LGA-3647 (Socket P)
Processor Chipset	Intel® C621

Rear IO:

# Rear 10Gbps RJ45 Ports	1
# Rear 1Gbps RJ45 Ports	1
# Rear 3.5mm Audio Jacks	5
# Rear USB 3.2 Gen 1 Type-A	4
# Rear USB 3.2 Gen 2 Type-A	1
# Rear USB 3.2 Gen 2 Type-C	1

Software:

Supported OS	Linux, Windows

Storage Bays:

# Dedicated 2.5Inch Bays	2
# Dedicated 3.5Inch Bays	8

Warranty:

Warranty Duration	36
Warranty Type	Return To Base Next Business Day Engineer Response
