WS-E1320A-G4 Enterprise AMD EPYC 3D Visualisation Workstation Full CPU Block Coverage All-In-One Liquid Cooling Solution 2x Intel i210-AT Gigabit RJ45 Network Ports 1x Gigabit Remote Management RJ45 Port
SKU: WS-E1320A-G4
The WS-E1320A-G4 is a well-rounded, cost-effective, enterprise class workstation specifically designed for high performance compute and CPU / GPU rendering workflows. Powered by a single AMD EPYC™ processor providing up to 32 cores & 64 threads, as well as compatibility for 1TB of 8-channel ECC Reg. DDR4 memory. The WS-E1320A-G4 can also be configured with up to 4 high performance AMD or NVIDIA graphics cards capable of accelerating your analytics, simulations and GPU renders to previously unimaginable levels
End of Life
System Configuration
End of Life
Details & Specifications
Details & Specifications
| Manufacturer | |
|---|---|
| System Type |
Desktop Workstation |
Dimensions:
| Item Depth (CM) |
41.5 |
|---|---|
| Item Height (CM) |
45.8 |
| Item Weight (Kg) |
18-22 |
| Item Width (CM) |
33.2 |
Front IO:
| # Front USB 3.2 Gen 1 Type-A |
2 |
|---|
Internal IO:
| # M.2 NVMe PCIe 3.0 x4 |
1 |
|---|---|
| # SlimSAS (for 4x SATA) |
1 |
Memory:
| DDR Rev. |
DDR4 |
|---|---|
| Max. Memory Capacity (GB) |
1024 |
| Max. Memory Channels |
8 |
| Memory Type |
ECC LRDIMM, ECC RDIMM |
PCIe:
| PCIe Configuration |
PCIe 3.0 x16: 4 (x16/x16/x16/x16) |
|---|
Processor:
| Processor Chipset |
System-on-Chip |
|---|---|
| Processor Generation |
AMD EPYC 2nd Gen. |
| Socket |
4094 / SP3 |
Rear IO:
| # Rear 1Gbps RJ45 Ports |
2 |
|---|---|
| # Rear USB 3.2 Gen 1 Type-A |
2 |
| Rear Remote Management LAN |
1 |
Software:
| Supported OS |
Linux, Windows Server 2019 |
|---|
Storage Bays:
| # Dedicated 2.5Inch Bays |
4 |
|---|---|
| # Front 5.25Inch Bays |
2 |
| # Universal 3.5/2.5Inch Bays |
2 |
Warranty:
| Warranty Duration |
36 Months |
|---|---|
| Warranty Type |
Return To Base |
* Specifications for older discontinued variants can be view by clicking here
