Details & Specifications

Dimensions:

Item Weight (Kg)	22-30
System Dimensions	24 x 60.4 x 56.6 cm (W x D x H)

Front IO:

# Front 3.5mm Audio Jacks	2
# Front USB 2.0 Type-A	2
# Front USB 3.2 Gen 1 Type-A	2
# Front USB 3.2 Gen 2 Type-C	1

Internal IO:

# Int USB 2.0 Header	2
# Int USB 3.2 Gen 2 Header	1
# Int USB 3.2 Gen1 Header	1
# M.2 NVMe PCIe 4.0 x4 / SATA	3 (Up to 22110)
# SATA3 (6Gbps) Ports	8
# U.2 Ports	2 *If M.2_2 slot is populated, U.2_1 slot is disabled. If M.2_3 slot is populated, U.2_2 slot is disabled.

Memory:

# Memory Slots	8
DDR Rev.	DDR4
Max. Memory Capacity (GB)	2048
Max. Memory Channels	8
Memory Type	ECC RDIMM, ECC UDIMM, Non-ECC UDIMM

PCIe:

PCIe Configuration	7 x PCIe 4.0/3.0 x16 slot(s)

Processor:

Processor Chipset	AMD WRX80
Processor Generation	AMD Ryzen™ Threadripper™ PRO 5000 WX-Series
Socket	4094, WRX8

Rear IO:

# Rear 10Gbps RJ45 Ports	2
# Rear USB 3.2 2x2 Type-C	1
# Rear USB 3.2 Gen 2 Type-A	8
# Rear USB 3.2 Gen 2 Type-C	1

Software:

Supported OS	Linux, Windows

Storage Bays:

# Dedicated 2.5Inch Bays	2
# Dedicated 3.5Inch Bays	6
# Front 5.25Inch Bays	2

Warranty:

Warranty Duration	36 Months
Warranty Type	Return To Base Next Business Day Engineer Response
