WS-1640A-G4 AMD Ryzen Threadripper Workstation

(3 customer reviews)

The WS-1640A-G4 is a Pro Visualisation Workstation based upon AMD’s ground-breaking 3rd Generation Ryzen Threadripper processors. This Workstation combines high cores/threads with super faster clockspeeds, support for a vast abundance of high bandwidth PCIe 4.0 lanes (64 in total) and high-speed system memory. The WS-1640A-G4 is our most powerful and well-rounded Workstation ever. Whether you are a 3D Content Designer, Post Production Visual Effects Artist, Product Designer, Architect, or in need super-fast CPU / GPU renders. Then this latest generation AMD Ryzen Threadripper Workstation has all the power and flexibility required to meet and exceed all your needs.

SKU: WS-1640A-G4 Category:

Dimensions:

Item Depth (CM)

53.3

Item Height (CM)

46.5

Item Weight (Kg)

18-22

Item Width (CM)

23.3

Front IO:

# Front USB 3.2 Gen 1 Type-A

2

Internal IO:

# Int USB 2.0 Header

1

# Int USB 3.2 Gen1 Header

2

# M.2 NVMe PCIe 4.0 x4

2

# M.2 NVMe PCIe 4.0 x4 / SATA

1

# SATA3 (6Gbps) Ports

8

Memory:

DDR Rev.

DDR4

Max. Memory Capacity (GB)

256

Max. Memory Channels

4

Memory Type

Non-ECC UDIMM

PCIe:

PCIe Configuration

PCIe 4.0 x16: 4 (x16/x8/x16/x8)

Processor:

Processor Chipset

AMD TRX40

Processor Generation

AMD Ryzen Threadripper 3rd Gen.

Socket

TRX4

Rear IO:

# Rear 10Gbps RJ45 Ports

1

# Rear 2.5Gbps RJ45 Ports

1

# Rear USB 3.2 2x2 Type-C

1

# Rear USB 3.2 Gen 1 Type-A

4

# Rear USB 3.2 Gen 2 Type-A

2

Software:

Supported OS

Linux, Windows 10

Storage Bays:

# Dedicated 2.5Inch Bays

2

# Universal 3.5/2.5Inch Bays

3

Warranty:

Warranty Duration

36 Months

Warranty Type

Return To Base
Next Business Day Engineer Response

3 reviews for WS-1640A-G4 AMD Ryzen Threadripper Workstation

  1. Eusebiu Pungaru

    Used for our VFX Production Company.

  2. Graham

    My new workstation arrived yesterday and I’m very happy with it, we ran a few tests on it yesterday compared to my current machine, and it blows it out of the water. My old machine was a dual xeon E2630V4 128gb ram.

    Corona render benchmark was 28seconds on the new machine, vs 1min 15 seconds on the old. and rendering one of our high end images at 6k was 1hr 52mins vs 6hrs 46mins!
    3x as fast Couldn’t be happier with it so far!

    Tom was super helpful during the ordering process, quick delivery and setup!

  3. Gaurav Verma

    Ryzen are the best solution for Architects
