Name: RS IXS-C621A0 G-U1N1-P2G0-E10I0 1U Rackmount Dual 3rd Gen Intel® Xeon® Scalable Server
SKU: RS IXS-C621A0 G-U1N1-P2G0-E10I0
Availability: OutOfStock

Home / Hidden Components / System / RS IXS-C621A0 G-U1N1-P2G0-E10I0 1U Rackmount Dual 3rd Gen Intel® Xeon® Scalable Server

Quick Links: Specifications, Reviews

RS IXS-C621A0 G-U1N1-P2G0-E10I0 1U Rackmount Dual 3rd Gen Intel® Xeon® Scalable Server

 0/5

Request A Quote

Details & Specifications

Chassis:

Chassis Form Factor	1U Rackmount
System Fans	8 x 40x40x56mm (29,700rpm)

Cooling:

Active Cooling	Yes

Dimensions:

Item Depth (CM)	78
Item Height (CM)	4.35
Item Width (CM)	43.8
Rack Units	1U

Front IO:

# Front USB 3.2 Gen 1 Type-A	1
LED	1 x Power button with LED 1 x ID button with LED 1 x Reset button 1 x NMI button 2 x LAN activity LEDs 1 x HDD activity LED 1 x System status LED

Internal IO:

# BIOS recovery switches	1
# Clear CMOS jumpers	1
# Front panel headers	1
# HDD back plane board headers	1
# Int USB 3.2 Gen1 Header	1
# IPMB connectors	1
# SATA 7-pin connectors	2
# VROC connectors	1
TPM Support	Yes

Memory:

# Memory Slots	32
DDR Rev.	DDR4
Max. Memory Capacity (GB)	8192
Max. Memory Channels	8
Max. Supported Memory Frequency (MHz)	3200
Memory Form Factor	DIMM
Memory Type	RDIMM / LRDIMM

PCIe:

PCIe Configuration	Riser Card CRS101E: – 1 x PCIe x16 slot (Gen4 x16), Full-height half-length Riser Card CRS101G: – 1 x PCIe x16 slot (Gen4 x16), Full-height half-length 1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth from CPU_0 Supported NCSI function 1 x OCP 2.0 mezzanine slot with PCIe Gen3 x8 bandwidth from CPU_1 Supported NCSI function

Power:

AC Input	100-240V~/ 12-7A, 50-60Hz 200-240V~/ 8A, 50-60Hz
DC Input	240Vdc/ 6.5A
DC Output	Max 1000W/ 100-240V~ 12V/ 80.5A 12Vsb/ 3A Max 1300W/ 200-240V~ or 240Vdc Input 12V/ 105.4A 12Vsb/ 3A

Processor:

# Processors	2
Processor Generation	3rd Generation Intel® Xeon® Scalable Processors
Socket	2 x LGA 4189 Socket P+
Processor Chipset	Intel® C621A Express Chipset

Rear IO:

# LED	1x ID button with LED
# RJ45 1Gb/s	2
# USB 3.2 Gen 1 Type-A	2
# VGA	1
Remote Management LAN	Yes

Software:

Supported OS	Linux, Windows Server

Storage Bays:

# Front 2.5 SATA Hotswap	8
# Front 2.5 SATA/Gen4 NVMe Hotswap	2

Video:

Onboard Graphics	Integrated in Aspeed® AST2600 2D Video Graphic Adapter with PCIe bus interface 1920×1200@60Hz 32bpp, DDR4 SDRAM

Warranty:

Mfr Warranty Length (M)	36
Mfr Warranty Type	Return to Base
