PCIe Configuration |
Riser Card CRS2014: – 1 x PCIe x16 slot (Gen4 x16), Occupied by CNV3134, 4 x NVMe HBA
Riser Card CRS2033: – 1 x PCIe x16 slot (Gen4 x16), FHHL – 1 x PCIe x8 slot (Gen4 x8), FHHL, Occupied by CNV3132, 2 x NVMe HBA – 1 x PCIe x8 slot (Gen4 x8), FHHL, Occupied by CNV3132, 2 x NVMe HBA
Riser Card CRS2033: – 1 x PCIe x16 slot (Gen4 x16), FHHL, Occupied by CNV3134, 4 x NVMe HBA – 1 x PCIe x8 slot (Gen4 x8), FHHL, Occupied by CNV3132, 2 x NVMe HBA – 1 x PCIe x8 slot (Gen4 x8), FHHL, Occupied by CNV3132, 2 x NVMe HBA
1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth from CPU_0 Supported NCSI function, Occupied by CNV9134, 4 x NVMe HBA
1 x OCP 2.0 mezzanine slot with PCIe Gen4 x8 bandwidth (Type1, P1, P2) Supported NCSI function, Occupied by CNVO132, 2 x NVMe HBA
|
