| Chassis Form Factor |
4U Rackmount |
|---|
| Active Cooling |
Yes |
|---|---|
| System Fans |
4 x 40x40x28mm (25,000rpm) |
| Item Depth (CM) |
88 |
|---|---|
| Item Height (CM) |
17.6 |
| Item Width (CM) |
44.8 |
| Rack Units |
4U |
| # 1Gbps RJ45 Ports |
2 |
|---|---|
| # NMI buttons |
1 |
| # Reset buttons |
1 |
| # USB 3.2 Gen 1 Type-A |
2 |
| # VGA |
1 |
| LED |
1 x Power button with LED |
| Remote Management LAN |
Yes |
| # Front panel headers |
1 |
|---|---|
| TPM Support |
Yes |
| # Memory Slots |
32 |
|---|---|
| DDR Rev. |
DDR4 |
| Max. Memory Capacity (GB) |
8192 |
| Max. Memory Channels |
8 |
| Max. Supported Memory Frequency (MHz) |
3200 |
| Memory Form Factor |
DIMM |
| Memory Type |
RDIMM/LRDIMM |
| PCIe Configuration |
10 x PCIe x16 slots (Gen3 x16 bus) for GPUs |
|---|
| AC Input |
100-127V~/ 14A, 47-63Hz |
|---|---|
| DC Output |
Max 1200W/ 100-127V~ |
| Efficiency Rating |
80 Plus Platinum |
| PSU |
3 x 2200W redundant PSUs |
| PSU Redundancy |
1 |
| Wattage |
2200 |
| # CPUs |
2 |
|---|---|
| Processor Generation |
AMD EPYC™ 7003 series processor family |
| Socket |
Socket SP3 |
| Processor Chipset |
System on Chip |
| # 10Gbps RJ45 Ports |
2 |
|---|---|
| Rear Remote Management LAN |
Yes |
| Supported OS |
Linux, Windows Server |
|---|
| # Front 2.5 SATA/SAS Hotswap |
2 |
|---|---|
| # Front 2.5 SATA/SAS/NVMe Hotswap |
8 |
| # Front 3.5 SATA/SAS Hotswap |
12 |
| Onboard Graphics |
Integrated in Aspeed® AST2500 |
|---|
| Mfr Warranty Length (M) |
36 |
|---|---|
| Mfr Warranty Type |
Return to Base |
