| Chassis Form Factor |
2U Rackmount |
|---|
| Active Cooling |
Yes |
|---|---|
| System Fans |
5 x 80x80x38mm (16,300rpm) |
| Item Depth (CM) |
82 |
|---|---|
| Item Height (CM) |
8.75 |
| Item Width (CM) |
43.8 |
| Rack Units |
2U |
| # NMI buttons |
1 |
|---|---|
| # Reset buttons |
1 |
| # USB 3.2 Gen 2 Type-A |
1 |
| LED |
1 x Power button with LED |
| # Front panel headers |
1 |
|---|---|
| TPM Support |
Yes |
| # Memory Slots |
8 |
|---|---|
| DDR Rev. |
DDR4 |
| Max. Memory Capacity (GB) |
2048 |
| Max. Memory Channels |
8 |
| Max. Supported Memory Frequency (MHz) |
3200 |
| Memory Form Factor |
DIMM |
| Memory Type |
RDIMM/LRDIMM |
| PCIe Configuration |
4 x PCIe x16 slots (Gen4 x16 bus) for GPU cards |
|---|
| # PSU |
2 |
|---|---|
| AC Input |
100-120V~/ 12A, 50-60Hz |
| DC Output |
Max 1000W/ 100-120V~ |
| Efficiency Rating |
80 Plus Platinum |
| PSU Redundancy |
1 |
| Wattage |
1600 |
| # CPUs |
1 |
|---|---|
| Processor Generation |
AMD EPYC™ 7003 series processor family |
| Socket |
Socket SP3 |
| Processor Chipset |
System on Chip |
| # ID LED |
1 |
|---|---|
| # USB 3.2 Gen 1 Type-A |
2 |
| # VGA |
1 |
| Rear Remote Management LAN |
Yes |
| Supported OS |
Linux, Windows Server |
|---|
| # Front 3.5 SATA Hotswap |
4 |
|---|---|
| # Rear 2.5 U.2/SAS/SATA Hotswap |
2 |
| Onboard Graphics |
Integrated in Aspeed® AST2600 |
|---|
| Mfr Warranty Length (M) |
36 |
|---|---|
| Mfr Warranty Type |
Return to Base |
