| Chassis Form Factor |
1U Rackmount |
|---|
| Active Cooling |
Yes |
|---|---|
| System Fans |
8 x 40x40x56mm (23'000rpm) |
| Item Depth (CM) |
73 |
|---|---|
| Item Height (CM) |
4.35 |
| Item Width (CM) |
43.8 |
| Rack Units |
1U |
| # USB 3.2 Gen 1 Type-A |
1 |
|---|---|
| LED |
1 x Power button with LED |
| # BIOS recovery jumper |
1 |
|---|---|
| # Clear CMOS jumpers |
1 |
| # COM header |
1 |
| # Front panel headers |
1 |
| # HDD back plane board headers |
1 |
| # IPMB connectors |
1 |
| # M.2 NVMe PCIe 3.0 x4 |
1 |
| # USB 3.2 Gen1 Header |
1 |
| TPM Support |
Yes |
| # Memory Slots |
32 |
|---|---|
| DDR Rev. |
DDR4 |
| Max. Memory Capacity (GB) |
8192 |
| Max. Memory Channels |
8 |
| Max. Supported Memory Frequency (MHz) |
3200 |
| Memory Form Factor |
DIMM |
| Memory Type |
RDIMM/LRIMM |
| PCIe Configuration |
Riser Card CRS101E: |
|---|
| # PSU |
2 |
|---|---|
| AC Input |
100-240V~/ 12-7A, 50-60Hz |
| DC Input |
240Vdc/ 6A |
| DC Output |
Max 1000W/ 100-240V~ |
| PSU Redundancy |
Yes |
| # Processors |
2 |
|---|---|
| Processor Generation |
AMD EPYC™ 7003 series processor family |
| Socket |
Socket SP3 |
| Processor Chipset |
System on Chip |
| # LED |
1x ID button with LED |
|---|---|
| # RJ45 1Gb/s |
2 |
| # USB 3.2 Gen 2 Type-A |
1 |
| # VGA |
1 |
| Rear Remote Management LAN |
Yes |
| Supported OS |
Linux, Windows Server |
|---|
| # Front 2.5 SATA Hotswap |
8 |
|---|---|
| # Front 2.5 SATA/NVMe Hotswap |
2 |
| Onboard Graphics |
Integrated in Aspeed® AST2500 |
|---|
| Mfr Warranty Length (M) |
36 |
|---|---|
| Mfr Warranty Type |
Return to Base |
