| Chassis Form Factor |
1U Rackmount |
|---|
| Active Cooling |
Yes |
|---|---|
| System Fans |
5 x 40x40x56mm (23'000rpm) |
| Item Depth (CM) |
66 |
|---|---|
| Item Height (CM) |
43.5 |
| Item Width (CM) |
43.8 |
| Rack Units |
1U |
| Front IO - # USB 3.2 Gen 1 Type-A |
1 |
|---|---|
| Front IO - LED |
1 x Power button with LED |
| # BIOS recovery jumpers |
1 |
|---|---|
| # Buzzers |
1 |
| # Clear CMOS jumpers |
1 |
| # COM_2 headers |
1 |
| # Front panel header |
1 |
| # HDD back plane board headers |
1 |
| # IPMB connectors |
1 |
| # M.2 NVMe PCIe 3.0 x4 |
2 |
| # PMBus connectors |
1 |
| # USB 2.0 headers |
1 |
| # USB 3.2 Gen1 headers |
1 |
| TPM Support |
Yes |
| # Memory Slots |
16 |
|---|---|
| DDR Rev. |
DDR4 |
| Max. Memory Capacity (GB) |
4096 |
| Max. Memory Channels |
8 |
| Max. Supported Memory Frequency (MHz) |
3200 |
| Memory Form Factor |
DIMM |
| Memory Type |
RDIMM/LRDIMM |
| PCIe Configuration |
Riser Card CRS101D: |
|---|
| # PSU |
2 |
|---|---|
| AC Input |
100-240Vac/ 10-5A, 50-60Hz |
| DC Input |
190-310V, 5-3A |
| DC Output |
650W |
| Efficiency Rating |
80 Plus Platinum |
| PSU Redundancy |
Yes |
| Wattage |
650 |
| # Processors |
1 |
|---|---|
| Processor Generation |
AMD EPYC™ 7003 series processor family |
| Socket |
Socket SP3 |
| Processor Chipset |
System on Chip |
| # COM |
1 |
|---|---|
| # RJ45 1Gb/s |
2 |
| # VGA |
1 |
| Rear IO - # USB 3.2 Gen 1 Type-A |
3 |
| Rear IO - LED |
1x ID button with LED |
| Rear Remote Management LAN |
Yes |
| Supported OS |
Linux, Windows Server |
|---|
| # Front 2.5 NVMe Hotswap |
2 |
|---|---|
| # Front 2.5 SATA Hotswap |
8 |
| Onboard Graphics |
Integrated in Aspeed® AST2500 |
|---|
| Mfr Warranty Length (M) |
36 |
|---|---|
| Mfr Warranty Type |
Return to Base |
