PNY NVIDIA RTX™ A4500
SKU: WEBGFXNQRTXA4500
The NVIDIA RTX™ A4500 is a high-performance Workstation class professional graphics card. This powerful GPU based on the NVIDIA Ampere architecture features 7,168 CUDA® cores, 2nd generation RT Cores, 3rd generation tensor cores and 20GB GDDR6 ECC memory. The NVIDIA RTX™ A4500 is ideally suited to memory-intensive workflows, highly complex/detailed rendering, and complex compute operations.
End of Life
System Configuration
End of Life
Details & Specifications
Details & Specifications
| Manufacturer | |
|---|---|
| Manufacturer Part Number |
VCNRTXA4500-PB |
Cooling:
| # Included Fans |
1 |
|---|
Dimensions:
| GPU Slot Size | |
|---|---|
| Item Depth (CM) |
11.18 |
| Item Width (CM) |
26.67 |
External IO:
| # Max Simultaneous Displays |
4 |
|---|---|
| Max Resolution |
HDR 7680 x 4320 at 60 Hz |
GPU:
| # CUDA Cores |
7168 |
|---|---|
| # Tensor Cores |
224 |
| GPU Architecture | |
| # RT Cores |
56 |
Memory:
| Memory Bandwidth (GB/s) |
640 |
|---|---|
| Memory Capacity (GB) |
20 |
| Memory Interface (bit) |
320 |
| Memory Type |
GDDR6 with ECC |
PCIe:
| PCIe Version |
PCIe 4.0 |
|---|
Power:
| # 8 Pin PCIe |
1 |
|---|---|
| Maximum Power Consumption |
200W |
Software:
| API Support |
CUDA, DirectCompute, DirectX 12.0, OpenCL, OpenGL 4.5, Shader Model 5.1, Vulkan 1.0 |
|---|---|
| Supported OS |
Linux, Windows |
| Technology Support |
HDCP, NVIDIA GPU Direct, NVIDIA MOSAIC, NVIDIA RTX Desktop Manager, Quadro Sync II |
Warranty:
| Mfr Warranty Length (M) |
36 |
|---|---|
| Mfr Warranty Type |
Direct To Manufacturer |
* Specifications for older discontinued variants can be view by clicking here
