PNY NVIDIA L40
SKU: NVBGPUNTL40
Categories: NVIDIA Data Centre GPUs
Modern visual computing and scientific applications are complex and diverse. They need data center solutions that can handle extreme performance and scale with versatile capabilities. The NVIDIA L40 is the ultimate visual computing solution for the data center. It has next-generation graphics, compute, and AI features to power GPU-accelerated applications.
The L40 is based on the Ada Lovelace GPU architecture. It has third-generation RT Cores for real-time ray tracing, and fourth-generation Tensor Cores for inferencing over a petaflop with FP8 support. It also has the latest CUDA Cores and 48GB of graphics memory to speed up visual computing workloads from virtual workstations to digital twins in NVIDIA Omniverse. The NVIDIA L40 delivers up to twice the performance of the previous generation at the same power. It is the ideal visual computing solution for the modern data center.
Details & Specifications
Details & Specifications
Manufacturer | |
---|---|
Manufacturer Part Number |
NVL40TCGPU-KIT |
Additional:
NVENC | NVDEC |
3x ENC | 3x DEC | Includes AV1 Encode and Decode |
---|---|
NVIDIA 3D Vision and 3D Vision Pro |
Support via Optional 3-pin mini-DIN Bracket |
vGPU Profiles Supported |
1 GB, 2 GB, 3 GB, 4 GB, 6 GB, 8 GB, 12 GB, 16 GB, 24 GB, 48 GB |
Cooling:
Frame Lock |
Supported with optional NVIDIA Quadro Sync II |
---|---|
NEBS ready |
Level 3 |
Dimensions:
Form Factor |
4.4" H x 10.5" L | Dual Slot |
---|---|
Secure Boot with Root of Trust |
Supported |
External IO:
# DisplayPort |
4x 1.4a |
---|---|
Max Resolution |
4x 5K at 60 Hz | 2x 8K at 60 Hz |
GPU:
# CUDA Cores |
18176 |
---|---|
# RT Cores |
142 | Gen 3 |
# Tensor Cores |
568 | Gen 4 |
# Transistors |
76.3 billion |
GPU Architecture | |
Lithography |
4nm |
Memory:
Memory Bandwidth (GB/s) |
864 |
---|---|
Memory Capacity (GB) |
48 |
Memory Interface (bit) |
384 |
Memory Type |
GDDR6 ECC² |
Power:
Max Power Consumption (W) |
300 |
---|---|
Power Connector |
1x PCIe CEM5 16-pinW |
Software:
Compute APIs |
CUDA 12.0, DirectCompute, OpenCL 3.0 |
---|---|
Graphics APIs |
DirectX 12 Ultimate, Shader Model 6.6, OpenGL 4.6, Vulkan 1.3 |
vGPU Software Support |
NVIDIA vApps, vPC, vWS | Early 2023 |
Supported OS |
Linux, Windows |
Warranty:
Mfr Warranty Length (M) |
36 |
---|---|
Mfr Warranty Type |
Direct To Manufacturer |
