HPC-R2640A-U1 AMD EPYC 1U Enterprise Server System
SKU: HPC-R2640A-U1
The HPC-R2640A-U1 is a high-density 2nd generation dual AMD EPYC based multi-purpose server. Ideally suited to a multitude of tasks requiring high CPU core counts such as rendering/simulation, web hosting, powering multiple Virtual Machines etc… the HPC-R2640A-U1 is a no-nonsense rock-solid server solution. With up to 128 cores, 256 threads, up to 4TB of system memory, full support for VMware vCenter and Gigabyte’s Server Management platform, this fully scalable solution is a system administrators dream.
Out Of Stock (End of Life)
System Configuration
Out Of Stock (End of Life)
Details & Specifications
Details & Specifications
Dimensions:
Item Depth (CM) |
73 |
---|---|
Item Height (CM) |
4.35 |
Item Weight (Kg) |
14-18 |
Item Width (CM) |
43.8 |
Rack Units |
1U |
Front IO:
# Front USB 3.2 Gen 1 Type-A |
2 |
---|
Internal IO:
# Int USB 3.2 Gen1 Header |
1 |
---|---|
# M.2 NVMe PCIe 3.0 x4 |
1 |
Memory:
DDR Rev. |
DDR4 |
---|---|
Max. Memory Capacity (GB) |
4096 |
Max. Memory Channels |
8 |
Memory Type |
ECC LRDIMM, ECC RDIMM |
PCIe:
PCIe Configuration |
PCIe 4.0 x16: 2 Full Height Half Length (Via Riser Cards) |
---|
Power:
# PSU |
2 |
---|---|
Efficiency Rating |
Platinum |
Wattage |
1200 |
Processor:
# CPUs |
2 |
---|---|
Processor Chipset |
System-on-Chip |
Processor Generation |
AMD EPYC 2nd Gen. |
Socket |
4094 / SP3 |
Rear IO:
# Rear 1Gbps RJ45 Ports |
2 |
---|---|
# Rear USB 3.2 Gen 1 Type-A |
2 |
Rear Remote Management LAN |
1 |
Software:
Supported OS |
Citrix Hypervisor, Red Hat, SUSE, Ubuntu, VMware ESXi, Windows 10, Windows Server 2016 |
---|
Storage Bays:
# Front 3.5 SATA Hotswap |
4 |
---|---|
# Int 2.5inch SATA |
2 |
Warranty:
Warranty Duration |
36 Months |
---|---|
Warranty Type |
Return To Base |
* Specifications for older discontinued variants can be view by clicking here
