HPC-R2280I-U1 Dual Intel Xeon Scalable 1U Server
SKU: HPC-R2280I-U1
Supporting dual Intel Xeon processors from the latest Scalable family the HPC-R2280I-U1 is a powerful space-efficient 1U server. With 24 memory slots enabling up to a massive 1,536GB of system memory, 4x 3.5″ hot-swap bays at the front for storage arrays and high-speed Dual 1Gb/s networking, this server is highly flexible. Also ideal for running virtual machines as the HPC-R2280I-U1 is validated for and fully compatible with VMware ESXi Hypervisor.
Out Of Stock (End of Life)
System Configuration
Out Of Stock (End of Life)
Details & Specifications
Details & Specifications
Dimensions:
| Item Depth (CM) |
73 |
|---|---|
| Item Height (CM) |
4.35 |
| Item Weight (Kg) |
13-16 |
| Item Width (CM) |
43.8 |
| Rack Units |
1U |
Front IO:
| # Front 1Gbps RJ45 Ports |
2 |
|---|---|
| # Front USB 3.2 Gen 1 Type-A |
2 |
Internal IO:
| # Int USB 3.2 Gen1 Header |
1 |
|---|
Memory:
| DDR Rev. |
DDR4 |
|---|---|
| Max. Memory Capacity (GB) |
3072 |
| Max. Memory Channels |
6 |
| Memory Type |
ECC LRDIMM, ECC RDIMM |
PCIe:
| PCIe Configuration |
PCIe 3.0 x8: 2 Low Profile Half Length |
|---|
Power:
| # PSU |
2 |
|---|---|
| Efficiency Rating |
Platinum |
| Wattage |
1200 |
Processor:
| # CPUs |
2 |
|---|---|
| Processor Chipset |
Intel C621 |
| Processor Generation |
Intel Xeon Scalable 1st Gen., Intel Xeon Scalable 2nd Gen. |
| Socket |
3647 / Socket P |
Rear IO:
| # Rear 1Gbps RJ45 Ports |
2 |
|---|---|
| # Rear USB 3.2 Gen 1 Type-A |
2 |
| Rear Remote Management LAN |
1 |
Software:
| Supported OS |
Citrix Hypervisor, Citrix Xenserver, Red Hat, SUSE, Ubuntu, VMware ESXi, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
|---|
Storage Bays:
| # Front 3.5 SATA/SAS Hotswap |
4 |
|---|---|
| # Int 2.5inch SATA |
1 |
| # Int 2.5Inch SATA/SAS |
1 |
Warranty:
| Warranty Duration |
36 Months |
|---|---|
| Warranty Type |
Return To Base |
* Specifications for older discontinued variants can be view by clicking here
