HPC-R2280-U4-G10 4U Rackmount Enterprise CPU/GPU Computing System

Our latest GPU compute server can now house even more GPUs than previous generations meaning more power and more density than ever before. Now with up to 10x GPU’s which is 2 more than any of our previous multi GPU server systems, whilst maintaining a dense 4U form factor. Combined with Dual Intel Xeon Scalable Family processors and up to 1.5TB of system memory, this solution is an exceptional Visual Computing Appliance (VCA) for network-assisted GPU renders or compute tasks for Simulations, Analysis and Artificial Intelligence / Deep Learning workflows.

SKU: HPC-R2280-U4-G10 Category:

With the ability to be configured with an additional 2 GPU’s over previous generations the HPC-R2280-U4-G10 has up to an additional 25% GPU compute performance over our other server alternatives. Combined with 2 of the very latest Enterprise Class Intel Xeon Scalable Family processors the HPC-R2280-U4-G10 makes for an extremely powerful and versatile Datacentre ready High Performance Compute Solution.

Due to the solutions compatibility with all major active and passive GPU’s including NVIDIA Tesla, NVIDIA Quadro, NVIDIA GeForce and AMD Radeon Pro, the HPC-R2280-U4-G10 can be configured to get the very most out of any application that benefits from GPU acceleration whether it is based upon OpenCL or CUDA standards.

Using the very latest NVIDIA Tesla GPUs this solution is ideal to help you drive your cutting edge Artificial Intelligence and Machine Learning algorithms, faster than ever before. By selecting the right GPU cards, this solution can be tailored to accelerate both training and inference workflows turning operations that once took weeks into days. Speak to our hardware consultancy team to discover the best configuration for your specific requirements.

Users can also take advantage of the NVIDIA Tesla GPUs in this solution to virtualise their workforce’s hardware via NVIDIA GRID technology. By housing your companies compute capabilities in a central location, either in-house or at a datacentre your workforce will no longer be tied to a large workstation under their desk and your system administrators will have more control over your hardware infrastructure. Applications from Dassault Systèmes, Autodesk, Adobe, PTC, Siemens as well as many more support NVIDIA GRID.

This server solution is also the most powerful GPU rendering solution in the Workstation Specialists Line up. Realtime rendering in large 4K resolutions has never been so close as with this system. With the combination of 10x NVIDIA Quadro, NVIDIA GeForce or AMD Radeon Pro graphics cards your renders can now be performed in record times. Should you require even more rendering performance consider adding additional HPC-R2280-U4-G10 systems to create a GPU rendering cluster. So long as your software supports networked GPU rendering these systems can scale exceptionally well, making the sky the limit in terms of rendering performance.

Dimensions:

Item Depth (CM)

88

Item Height (CM)

17.6

Item Weight (Kg)

39

Item Width (CM)

44.8

Front IO:

# Front 1Gbps RJ45 Ports

2

# Front USB 3.2 Gen 1 Type-A

2

Front Remote Management LAN

1

Memory:

DDR Rev.

DDR4

Max. Memory Capacity (GB)

3072

Max. Memory Channels

6

Memory Type

ECC LRDIMM, ECC RDIMM

PCIe:

PCIe Configuration

PCIe 3.0 x16: 10 (Runs at x16) for GPUs
PCIe 3.0 x16: 1 (Runs at x16) Half-length low-profile slot in rear

Power:

# PSU

3

Efficiency Rating

Platinum

Wattage

2200

Processor:

# CPUs

2

Processor Chipset

Intel C621

Processor Generation

Intel Xeon Scalable 1st Gen., Intel Xeon Scalable 2nd Gen.

Socket

3647 / Socket P

Rear IO:

# Rear 10Gbps RJ45 Ports

2

Rear Remote Management LAN

1

Software:

Supported OS

Citrix Hypervisor, Citrix Xenserver, Red Hat, SUSE, Ubuntu, VMware ESXi, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Storage Bays:

# Front 2.5 SATA/SAS Hotswap

2

# Front 2.5 U.2 NVMe Hotswap

8

# Front 3.5 SATA/SAS Hotswap

12

Warranty:

Warranty Duration

36 Months

Warranty Type

Return To Base
Next Business Day Engineer Response
