HPC-R2280-U1-G4 1U Rackmount Enterprise CPU/GPU Computing System

The Workstation Specialists HPC-R2280-U1-G4 is a high-performance GPU rackmount server in a high-density 1U form factor. By combining 2 of Intel’s latest Xeon Scalable Family processors (up to 56 Cores, 112 Threads) and 4 NVIDIA GeForce, Quadro or Tesla GPU’s the HPC-R2280-U1-G4 has comfortably enough compute performance for today’s Artificial Intelligence, Scientific Simulation, Virtualisation or GPU rendering workflows.

SKU: HPC-R2280-U1-G4 Category:

Workstation Specialists High Performance Compute (HPC-) range of rackmount servers have all been designed from the ground up to excel specifically with the demands of today’s datacentre based applications.

The HPC-R2280-U1-G4 takes full advantage of the Intel Xeon Scalable Processors, enabling higher processor cores counts (up to 56 Cores, 112 Threads) than previously possible. Combined with the flexibility that the additional 4x GPU’s offer, this rackmount server solution can be configured to thrive across all modern datacentre workflows.

Artificial Intelligence / Deep Learning / GPU Compute Sever

Configure this server with up to 4x NVIDIA Tesla GPU’s including the very latest NVIDIA Tesla V100 featuring the exceptional NVIDIA Volta architecture for maximum performance enabling users to perform simulations, deep learning training and inference tasks in days when it would once took weeks. With the high density form factor of only 1U rackmount space per system you can cluster multiple HPC-R2280-U1-G4 together to obtain ever greater heights of performance.

NVIDIA GRID Server

If you are interested in centralising your compute power and virtualising your workforce then NVIDIA GRID is the perfect technology for you. By sharing the HPC-R2280-U1-G4’s computing resources over many users, your 3D content designers can experience full powered graphically accelerated workstation performance anytime, anywhere. All your users will require is an internet connection and lower powered computer, laptop or tablet. Contact one of our consultancy team for more details.

GPU Rendering Server

With full compatibility with either 4x NVIDIA Quadro or 4x AMD Radeon Pro WX series graphics cards the HPC-R2280-U1-G4 makes an exceptional network GPU render node. Experience near real-time photorealistic renders within NVIDIA Iray, NVIDIA Mental Ray, AMD ProRender, Otoy Octane, Redshift, Chaos Group VrayRT and many more… Speak to one of our consultancy team today who specialise in finding users the perfect configuration to keep your rendering times to a minimum and ensuring you get the maximum performance for your budget.

Dimensions:

Item Depth (CM)

89.4

Item Height (CM)

4.3

Item Weight (Kg)

20.4

Item Width (CM)

43.7

Rack Units

1U

Internal IO:

# M.2 NVMe PCie 3.0 x4 / SATA

1

Memory:

DDR Rev.

DDR4

Max. Memory Capacity (GB)

3072

Max. Memory Channels

6

Memory Type

ECC LRDIMM, ECC RDIMM

PCIe:

PCIe Configuration

PCIe 3.0 x16 FHFL: 4 (runs at x16,x16,x16,x16)
PCIe 3.0 x16 LP: 1 (runs at x16)
PCIe 3.0 x8 LP: 1 (runs at x8)

Power:

# PSU

2

Efficiency Rating

Titanium

Wattage

2000

Processor:

# CPUs

2

Processor Chipset

Intel C621

Processor Generation

Intel Xeon Scalable 2nd Gen.

Socket

3647 / Socket P

Rear IO:

# Rear 10Gbps RJ45 Ports

2

# Rear USB 3.2 Gen 1 Type-A

2

Rear Remote Management LAN

1

Software:

Supported OS

CentOS, Citrix Xenserver, Fedora, FreeBSD, Hyper-V Server 2016, Oracle Linux, Red Hat, Solaris, SUSE, Ubuntu, VMware ESXi, Windows 10, Windows 8.1, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Storage Bays:

# Front 2.5 U.2 NVMe Hotswap

2

# Int 2.5inch SATA

2

Warranty:

Warranty Duration

36 Months

Warranty Type

Return To Base
Next Business Day Engineer Response
