3rd Gen Intel® Xeon® Scalable, DDR4 ECC Reg. Memory, 3x GPU, 2x M.2, 2x 10Gb/s [WS IXS-C621A0]
SKU: WS IXS-C621A0
3rd Gen Intel® Xeon® Scalable, DDR4 ECC Reg. Memory, 3x GPU, 2x M.2, 2x 10Gb/s [WS-IXS C621A0]
Variant Images and Technical Specifications: Click Here
Out Of Stock (End of Life)
System Configuration
Out Of Stock (End of Life)
Details & Specifications
Details & Specifications
Dimensions:
Item Depth (CM) |
59 |
---|---|
Item Height (CM) |
54.8 |
Item Weight (Kg) |
16.53 |
Item Width (CM) |
24 |
Front IO:
# Front 3.5mm Audio Jacks |
2 |
---|---|
# Front USB 2.0 Type-A |
2 |
# Front USB 3.2 Gen 1 Type-A |
2 |
# Front USB 3.2 Gen 2 Type-C |
1 |
Internal IO:
# Int USB 3.2 Gen1 Header |
1 |
---|---|
# M.2 NVMe PCIe 4.0 x4 |
2 |
# SATA3 (6Gbps) Ports |
7 |
# SlimSAS (for 4x SATA) |
3 |
Memory:
# Memory Slots |
16 |
---|---|
DDR Rev. |
DDR4 |
Max. Memory Capacity (GB) |
2048 |
Max. Memory Channels |
8 |
Memory Type |
ECC LRDIMM, ECC RDIMM |
PCIe:
PCIe Configuration |
6x PCIe 4.0 x16 (runs at x16) |
---|
Processor:
Processor Generation |
3rd Generation Intel® Xeon® Scalable Processors |
---|---|
Socket |
2 x LGA 4189 (Socket P+) |
Processor Chipset |
Intel® C621A Express Chipset |
Rear IO:
# Rear 10Gbps RJ45 Ports |
2 |
---|---|
# Rear 1Gbps RJ45 Ports |
2 |
# Rear USB 3.2 Gen 1 Type-A |
2 |
VGA |
1 |
Software:
Supported OS |
Linux, Windows Server 2016, Windows Server 2019 |
---|
Storage Bays:
# Int 2.5inch SATA |
2 |
---|---|
# Int 3.5inch SATA |
8 |
Warranty:
Warranty Duration |
36 |
---|---|
Warranty Type |
Return To Base |
* Specifications for older discontinued variants can be view by clicking here
