WS IXS-C7410-P2 4th Gen Intel® Xeon® Scalable Workstations
SKU: WS IXS-C7410-P2
System Configuration
Details & Specifications
Details & Specifications
Dimensions:
| WxDxH |
22 x 46.9 x 49 cm |
|---|
Front IO:
| # Front 3.5mm Audio Jacks |
2 |
|---|---|
| # Front USB 2.0 Type-A |
2 |
| # Front USB 3.2 Gen 1 Type-A |
2 |
| # Front USB 3.2 Gen 1 Type-C |
1 |
Internal IO:
| # Int USB 2.0 Header |
1 |
|---|---|
| # Int USB 3.2 Gen 2 Header |
1 |
| # Int USB 3.2 Gen1 Header |
1 |
| # M.2 NVMe PCIe 5.0 x4 |
2 |
| # SATA3 (6Gbps) Ports |
8 SATA3 ports; RAID 0, 1, 5, 10 |
Memory:
| # Memory Slots |
16 |
|---|---|
| DDR Rev. |
DDR5 |
| Max. Memory Capacity (GB) |
4096 |
| Max. Memory Channels |
8 |
| Memory Type |
3DS RDIMM, RDIMM |
PCIe:
| PCIe Configuration |
1 PCIe 5.0 x8 |
|---|
Processor:
| Processor Generation |
4th Gen Intel® Xeon® Scalable |
|---|---|
| Socket |
Dual LGA-4677 (Socket E) |
| Processor Chipset |
Intel® C741 |
Rear IO:
| # Rear 10Gbps RJ45 Ports |
2 |
|---|---|
| # Rear 3.5mm Audio Jacks |
3 |
| # Rear USB 3.2 Gen 1 Type-A |
4 |
| # VGA |
1 |
Software:
| Management |
SuperDoctor® 5, SPM, SUM, SSM, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, Watchdog, SMCIPMITool, Trusted Platform Module (TPM), CPU thermal trip support for processor protection, Wake-on-LAN |
|---|---|
| Supported OS |
Linux, Windows, Windows Server |
Storage Bays:
| # Dedicated 2.5Inch Bays |
2 |
|---|---|
| # Dedicated 3.5Inch Bays |
6 |
Warranty:
| Warranty Duration |
36 |
|---|---|
| Warranty Type |
Return To Base |
* Specifications for older discontinued variants can be view by clicking here
